Customer case study with Uniworx®, the universal milling cutter for finish machining.
13. January 2026
Uniworx® processes GGG70
58HRC + 65HRC
Uniworx® processes GGG70
| 58HRC | 65HRC | |
| Tool | 16 214 SG | 16 214 SG |
| dc (nominal diameter) | 16 mm | 0.6299 inch | 16 mm | 0.6299 inch |
| Arbor | 50 16 A63 + 25 10 603 | 25 10 603 |
| Cooling | dry | Minimum quantity lubrication system |
| Indexable insert | 16 093 V R7 | 16 093 V R7 |
Technical data | metric sizes
| 58HRC | 65HRC | |
| Vc (cutting speed) | 603 m/min | 1100 m/min |
| n (revoltions) | 12000 1/min | 22000 1/min |
| fz (feed per tooth) | 0,2 mm | 0,34 mm |
| Vf (feed rate) | 4800 mm/min | 15000 mm/min |
| ap (depth of cut) | 0,2 mm | 0,3 mm |
| ae (width of cut) | 0,3 mm | 0,3 mm |
| Processing time | 1080 Min | 180 Min |
| End of tool life | not achieved | not achieved |
Technical data | imperial sizes
| 58HRC | 65HRC | |
| SFM (surface feet per minute) | 1978.35 feet/min | 3608.924 feet/min |
| n (revoltions) | 12000 1/min | 22000 1/min |
| IPT (inches per tooth) | 0.0079 inch | 0.0134 inch |
| IPM (inches per minute) | inch/min | inch/min |
| DOC (depth of cut) | 0.0079 inch | 0.0118 inch |
| WOC (width of cut) | 0.0118 inch | 0.0118 inch |
| Processing time | 1080 Min | 180 Min |
| End of tool life | not achieved | not achieved |
