13. January 2026

Uniworx® processes GGG70

  • Customer case studies
  • Milling cutter bodies
  • Uniworx®
  • Cast iron

Customer case study with Uniworx®, the universal milling cutter for finish machining.

Uniworx® processes GGG70

 Variant 1Variant 2
Tool12 214 SG without ICS12 214 SG with ICS
Arbor40 07 60340 07 603
Coolingcoat with oilMMS Internal
Indexable insert12 093 V R512 093 V R5



Technical data | metric sizes

 Variant 1Variant 2
Vc (cutting speed)528 m/min528 m/min
n (revoltions)14000 1/min14000 1/min
fz (feed per tooth)0,25 mm0,25 mm
Vf (feed rate)7000 mm/min7000 mm/min
ap (depth of cut)0,15 mm0,15 mm
ae (width of cut)0,25 mm0,25 mm
Machining volume0,26 cm³/min0,26 cm³/min
Service life1020 Min1800 Min

Technical data | imperial sizes

 Variant 1Variant 2
SFM (surface feet per minute)1732.28 feet/min1732.28 feet/min
n (revoltions)14000 1/min14000 1/min
IPT (inches per tooth)0.0098 inch0.0098 inch
IPM (inches per minute)275.5906 inch/min275.5906 inch/min
DOC (depth of cut)0.0059 inch0.0059 inch
WOC (width of cut)0.0098 inch0.0098 inch
Machining volume0.1024 inch³/min0.1024 inch³/min
Service life1020 Min1800 Min
