Application data

Quadworx® product family - imperial sizes
  • Homepage
  • Quadworx application data imperial

Quadworx® L

Coating
grade		SteelStainless steelCast ironNon-ferrous metals /
non-metals		High-temperature
resistent alloys		Hardened
materials
P40 PVTiP
1: 328 - 820
2: 0.020 - 0.098
3: 0.012 - 0.059		-----
P40 PVGOP
1: 328 - 656
2: 0.020 - 0.098
3: 0.012 - 0.059		-----
P25 PVTiP
1: 328 - 984
2: 0.020 - 0.098
3: 0.012 - 0.059		-----
K10 PVTi--P
1: 492 - 656
2: 0.020 - 0.098
3: 0.012 - 0.067		--P
1: 328 - 820
2: 0.012 - 0.059
3: 0.012 - 0.031
M40 PVST-P
1: 262 - 820
2: 0.012 - 0.059
3: 0.010 - 0.051		--P
1: 98 - 394
2: 0.012 - 0.039
3: 0.010 - 0.035		-

P: primary application | S: secondary application
1: spindle speed (SFM in feet per minute) | 2: feed rate (IPT in inches) | 3: depth of cut (DOC in inches)

Quadworx® XL

Coating
grade		SteelStainless steelCast ironNon-ferrous metals /
non-metals		High-temperature
resistent alloys		Hardened
materials
P40 PVGOP
1: 328 - 820
2: 0.004 - 0.020
3: 0.008 - 0.315		-S
1: 361 - 591
2: 0.004 - 0.020
3: 0.008 - 0.315		---
P25 PVGOP
1: 361 - 984
2: 0.004 - 0.020
3: 0.008 - 0.315		-P
1: 394 - 820
2: 0.004 - 0.020
3: 0.002 - 0.315		---
M40 PVST-P
1: 262 - 820
2: 0.002 - 0.012
3: 0.004 - 0.236		--P
1: 98 - 394
2: 0.002 - 0.010
3: 0.010 - 0.236		-

P: primary application | S: secondary application
1: spindle speed (SFM in feet per minute) | 2: feed rate (IPT in inches) | 3: depth of cut (DOC in inches)
